Product Details:
|
| Name: | Factory Direct Price Orange Dredging Pipe Float Plastic Pontoon Floater For Dredging | Material: | Out Shell PE, Inner Foam: PU |
|---|---|---|---|
| Color: | Orange /Yellow | Dimension: | DN60-1200mm |
| Connection: | Galvanised Bolts Nuts And Washers | Shape: | Clinder |
| Highlight: | float boat buoy,8 inch poly pipe floats,floating buoy for ship |
||
Dredger Floaters Pipe Floats for Dredging Pipes DN500
Features of Jiubei Polyethylene Foam Float:
1. Long life, more than 50 years under normal conditions.
2. Good corrosion resistance, resistant to a variety of chemical intermediates.
3 .Good resistance to crack growth.
4. low coefficient of friction and low flow resistance.
5. Excellent wear resistance, its wear resistance is 4 times that of steel pipe under normal conditions.
6. Good weldability, its interface strength is higher than that of pipe body.
7. Good flexibility and scratch resistance.
8 .Very high impact resistance.
9. Unique low temperature resistance, usable at -40-60°C.
10. Light weight, 1/8 steel pipe, easy to transport and install.
11. Soft metal flange for connection, easy to install and remove.
12. Smooth inner wall, easy to transport by pipeline.
PE Float Dimension:
| Float I.D. (mm) | Float O.D.(mm) | Float Length(mm) | Thickness of Hull(mm) | Floater Buoyancy (kg) |
| 110 | 500 | 500 | 7 | 98 |
| 125 | 500 | 800 | 7 | 150 |
| 160 | 500 | 800 | 7 | 145 |
| 220 | 600 | 700 | 7 | 180 |
| 250 | 600 | 700 | 7 | 175 |
| 280 | 700 | 900 | 7 | 340 |
| 310 | 900 | 1000 | 8 | 550 |
| 320 | 1000 | 1000 | 9 | 650 |
| 350 | 950 | 1000 | 9 | 600 |
| 390 | 1000 | 1000 | 9 | 600 |
| 400 | 1100 | 1100 | 9 | 900 |
| 450 | 1200 | 1200 | 11 | 1100 |
| 460 | 1300 | 1300 | 12 | 1400 |
| 495 | 1300 | 1300 | 12 | 1400 |
| 520 | 1300 | 1450 | 12 | 1500 |
| 550 | 1300 | 1500 | 12 | 1750 |
| 560 | 1400 | 1500 | 12 | 1900 |
| 600 | 1400 | 1600 | 13 | 2100 |
| 620 | 1450 | 1700 | 13 | 2400 |
| 670 | 1500 | 1860 | 14 | 2800 |
| 720 | 1500 | 1860 | 14 | 2800 |
| 735 | 1500 | 1800 | 14 | 2700 |
| 760 | 1800 | 2050 | 15 | 3100 |
| 800 | 1800 | 2160 | 15 | 3300 |
| 890 | 2000 | 2400 | 15 | 4600 |
| 940 | 2040 | 2500 | 16 | 4900 |
| 1040 | 2400 | 2600 | 16 | 7000 |
| 1140 | 2300 | 2550 | 16 | 7000 |
